Competitive Price for Uv Printer A1 - RB-1016 A0 Large Size Industrial UV Flatbed Printer – Rainbow Detail:
RB-1016 A0 Large Size Industrial UV Flatbed Printer
RB-1016 A0 UV flatbed printer can print on rotary and flat material with all color just by one printer. It can print CMYK, White and Varnish at the same time. The Max Printing Size is 160*100cm.
Model |
RB-1016 A0 UV Flatbed Printer |
Printhead Number |
Three DX10/4720 Print Heads |
Max Printing |
160*100cm |
Printing Height |
3cm-25cm(Adjustable) |
Printing Speed |
17 m2/h (720*720DPI) |
12 m2/h (720*1440DPI) |
8 m2/h (1440*1440DPI) |
Optional Printing Color |
CMYK+White+Varnish |
Maximum Resolution |
720*4320DPI |
Printing Materials |
Plastic, Acrylic, Wood, Ceramic Tile, Glass, Leather, Metal, Phone Case etc. |
Printing Software |
Maintop/ Photoprint |
Picture Mode |
PSD/ TIFF/ BMP/ EPS/ JPG |
Working Environment |
Temperature 25-30℃; Humidity 40%~60% |
Computer System |
Windows 7/Window 8/Window 10 |
Machine Size |
2.8*1.66*1.38m |
Date Interface |
USB3.0 High Speed Interface Transfer System |
Power |
50-60Hz, 1000-1500W |
Package Size |
2.92*1.8*1.22m |
Machine Weight |
Net.530KG/Gross.630KG |
|
|
|
RB-1016 UV Printer Igus Belt
|
Ink Alarm System |
Water-cooled Circulation System |
Well protected lines and water pipes, no deformation for decades using. |
Rainbow newest version updated with 500ML big tank for cyan, magenta, yellow,black,white and varnish; The white ink circulation system work constantly keep white ink from sediment and last the lifespan of print head. Besides, it has ink-alarming system which will mention you to add ink if the ink is in shortage. |
The system ensures that the LED lamp maintains a constant temperature,extending the LED lamp to 50,000 hours, avoiding high temperature hurt. |
|
|
|
Rotary Printing for Bottle Mugs |
Quick Control Buttons |
Vacuum adsorption platform |
3Pcs Epson DX10/4720 heads, can print CMYK+White+Varnish inks together. |
It's more stable for printing with size 160*100cm and 25cm height. |
For print both soft and hard materials. solid enough for undertake maximum 100kg weight. |
|
|
|
Rotary Printing for Bottle Mugs |
Quick Control Buttons |
Firm Ball Screw |
Bigger size rotary printing(both mugs and bottles), driven by an indepentment motor, which makes the printing process more stable and get high resolution. |
Emergency Stop Button+Fan Button+Rotary Switch. It's very easy to operate. |
Imported stainless steel silent rail from Japan. Long working hours, anti-deformation, anti-oxidation, corrosion resistance. |
Samples
Customer Feedback
Our Company
FAQ
Q1:What materials can UV printer print?
A:UV printer can print almost all kinds materials, such as phone case, leather, wood,plastic, acrylic, pen, golf ball, metal, ceramic, glass, textile and fabrics etc.
Q2:Can UV printer print embossing 3D effect?
A:Yes, it can print embossing 3D effect, contact us for more information and printing videos
Q3:Can A3 uv flatbed printer do rotary bottle and mug printing?
A:Yes, both bottle and mug with handle can be printed with the help of rotary printing device.
Q4:Does printing materials must be sprayed a pre-coating?
A:Some material need pre-coating, such as metal, glass, acrylic for make the color anti-scratch.
Q5:How can we start to use the printer?
A:We will send the detailed manual and teaching videos with the package of the printer before use the machine, please read the manual and watch the teaching video and operate strictly as the instructions, and if any question unclarified, our technical support online by teamviewer and video call will be help.
Q6:What about the warranty?
A:We have 13 months warranty and lifelong technical support, not include consumables like print head and ink dampers.
Q7:What's the printing cost?
A:Usually,1 square meter need cost about $1 printing cost with our good quality ink.
Q8:Where can I buy the spare parts and inks?
A:All spare parts and ink will be available from us during the whole lifespan of printer, or you can buy at local.
Q9:What about maintenance of the printer?
A:The printer has auto-cleaning and auto keep wet system, each time before power off machine, please do a normal cleaning so that keep print head wet. If you don't use the printer more than 1 week, it’s better to power on machine 3 days later to do a test and auto clean.
